(In Stock!) Maytech New 12.5KW Electric Waterjet Propulsion System MTWJ12KW For Electric Boat Jetboard
(In Stock!) Maytech New 12.5KW Electric Waterjet Propulsion System MTWJ12KW For Electric Boat Jetboard
SKU:MTWJ12KW
Regular price
$985.42
Regular price
$1,015.90
Sale price
$985.42
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Have Doubts? Contact US!!
Have Doubts? Contact US!!
Maytech New 12.5KW Electric Waterjet Propulsion System MTWJ12KW For Electric Boat Jetboard
Specifications: Including Motor + Jet pump
Max Thrust at Different Volts At Full Throttle |
||||||||
| Voltage (V) | Current (A) | Input Power (W) | RPM |
Motor Temp (℃) |
Thrust (kgf) |
Throttle (%) |
Thrust/Power (kgf/kw) |
|
| 1 | 60 | 134 | 8040 | 6508 | 47 | 70.6 | 100 | 8.781094527 |
| 2 | 67 | 155 | 10385 | 7133 | 56 | 77.2 | 100 | 7.433798748 |
| 3 | 72 | 163 | 11736 | 7631 | 67 | 80.2 | 100 | 6.833674165 |
| 4 | 75 | 165 | 12375 | 7987 | 64 | 83.1 | 100 | 6.715151515 |
| 5 | 80 | 167 | 13360 | 8364 | 79 | 85.4 | 100 | 6.392215569 |
| 6 | 84 | 171 | 14364 | 8793 | 99 | 87.1 | 100 | 6.063770537 |
| Model No | MTWJ12KW-125 |
| Voltage range(LiPo) | 60-84V（20S） |
| Max Spin Speed(RPM) | 10500 |
| KV Speed Constance kV(RPM/V) | 125KV |
| A Torque Constance Kt(N*M/A) | 0.10082 |
| Current @8.4V without Loading(A) | 2.2A |
| Max Power（KW） | 15.8 |
| Peak current（A） | 300 |
| Max Effeciency | 94% |
| Max torque@60%(N*M) | 31.8 |
| Rating Power(KW) | 12.5 |
| Rating Torque (N*M) | 21 |
| Construction | 12N/10P |
| Max working temperature | 120︒C |
| Insulation voltage & leak current | AC500V/10MA/3S |
| Lead wires extension | 6AWGx300mm |
| Thermal resistor | TP1000 |
| Thermal resistor connector | Runlai RL-M12-2 |
| Plug | TM25-6 |
Download:
MTWJ12KW Water Jet Motor Test Curve at 60V
Maytech MTWJ12KW Water Jet with Motor Testdata
Drawing:
Test Curves:
Test Datas:
Test Video:
