50pcs 4260 600KV/750KV/850KV Brushless Outrunner Sensorless Motor Open Cover for Rc Airplane/Helicopter/Robotics

50pcs 4260 600KV/750KV/850KV Brushless Outrunner Sensorless Motor Open Cover for Rc Airplane/Helicopter/Robotics

SKU:MTO4260-G with accessories

Prezzo di listino $3,218.50
Prezzo di listino $4,023.10 Prezzo scontato $3,218.50
In offerta Esaurito
Spese di spedizione calcolate al check-out.
KV
Quantity MOQ

Have Doubts? Contact US!!

50pcs 4260 600KV/750KV/850KV Brushless Outrunner Sensorless Motor Open Cover for Rc Airplane/Helicopter/Robotics

Model

No

KV Shaft (mm) Max. Current Input Volt. Net
Weight (g)
Stator Size Motor Size Thurst (g) WATT.
MTO4260 -600-G 600 Ф5.0 56A 4-6S Li-Po  280

Ф35.0X

42.0

Ф42.0X

59.5

2800 520W
MTO4260 -750-G 750 Ф5.0 65A 4-6S Li-Po 280

Ф35.0X

42.0

Ф42.0X

59.5

4700 1150W
MTO4260 -850-G 850 Ф5.0 75A 4-6S Li-Po 280

Ф35.0X

42.0

Ф42.0X

59.5

3800 907W



MOQ is 50pcs/order for this motor. Motor logo can be customized. You can order different KVs (For example, order of  25pcs 600KV + 25pcs 750KV is ok).

For more details or customized motors, please contact support@michobby.com .

Test datasheet:

4260 600KV/750KV/850KV Brushless Outrunner Sensorless Motor Open Cover for Rc Airplane/Helicopter/Robotics
Features:

  • The up and bottom caps are made of aluminium alloy.
  • The motor case is made of steel.
  • The static balance is confirm.
  • NSK Japanese bearings
  • 45h sintered ndfeb magnets
  • Stator is stacked with silicon steel
  • Use high temperature and oxygen-free copper wire
  • Stainless steel shaft
  • High-temperature micro ball-bearing

Drawing:

4260 620KV/750KV/850KV Brushless Outrunner Sensorless Motor Open Cover for Rc Airplane/Helicopter/Robotics
