50pcs 2830 750KV/850KV/1000KV/1300KV Brushless Outrunner Sensorless Motor Open Cover for Rc Airplane/Helicopter/Robotics
50pcs 2830 750KV/850KV/1000KV/1300KV Brushless Outrunner Sensorless Motor Open Cover for Rc Airplane/Helicopter/Robotics
SKU:MTO2830-G with accessories
Prezzo di listino
$708.80
Prezzo di listino
$885.99
Prezzo scontato
$708.80
Prezzo unitario
per
Spese di spedizione calcolate al check-out.
Impossibile caricare la disponibilità di ritiro
Have Doubts? Contact US!!
Have Doubts? Contact US!!
50pcs 2830 750KV/850KV/1000KV/1300KV Brushless Outrunner Sensorless Motor Open Cover for Rc Airplane/Helicopter/Robotics
| Model No | KV | Shaft (mm) | Max. Current | Input Volt. | Net Weight (g) |
Stator Size | Motor Size | Thurst (g) | WATT. |
| MTO2830-750-G | 750 | Ф3.17 | 12.5A | 2-4S Li-Po | 55 |
Ф22.0X 12.0 |
Ф27.8x 29.5 |
866 | 185W |
| MTO2830-850-G | 850 | Ф3.17 | 12.9A | 2-4S Li-Po | 55 |
Ф22.0X 12.0 |
Ф27.8x 29.5 |
875 | 187W |
| MTO2830-1000-G | 1000 | Ф3.17 | 14.5A | 2-4S Li-Po | 55 |
Ф22.0X 12.0 |
Ф27.8x 29.5 |
890 | 210W |
| MTO2830-1300-G | 1300 | Ф3.17 | 19A | 2-4S Li-Po | 55 |
Ф22.0X 12.0 |
Ф27.8x 29.5 |
930 | 275W |
MOQ is 50pcs/order for this motor. Motor logo can be customized. You can order different KVs (For example, order of 25pcs 1100KV + 25pcs 1250KV is ok).
For more details or customized motors, please contact support@michobby.com .
Test Datasheet:
Features:
- The up and bottom caps are made of aluminium alloy.
- The motor case is made of steel.
- The static balance is confirm.
- NSK Japanese bearings
- 45h sintered ndfeb magnets
- Stator is stacked with silicon steel
- Use high temperature and oxygen-free copper wire
- Stainless steel shaft
- High-temperature micro ball-bearing
Drawing:
