MTO6355-170/190-HA-C 6355 170KV 190KV Brushless Outrunner Sensored Motor Black Sealed Cover (8mm shaft)
MTO6355-170/190-HA-C 6355 170KV 190KV Brushless Outrunner Sensored Motor Black Sealed Cover (8mm shaft)
SKU:MTO6355-170-HA-C
No se pudo cargar la disponibilidad de retiro
Have Doubts? Contact US!!
Have Doubts? Contact US!!
6355 170KV / 190KV Brushless Outrunner Sensored Motor with Black Closed Cover IP54 Splash Waterproof for Esk8/Robotics
| Model NO | MTO6355-170/190-HA-C |
| Motor KV | 170 or 190 (RPM/V) |
| Shaft | 8mm shaft with 3mm keyway |
| Idle Curren | 1.0A |
| Max. Current | 65A |
| Input Volt | 2-12Lipo cell |
| Max. Output Watt | 3510W |
| Max. Pull | 12000g |
| Net Weight | 605g |
| Motor Diameter | 63mm |
| Internal Resistance | 0.0441 |
| Hall Sensor | sensored |
| Application | For electric skateboard and E-bike |
| Features | With dustproof and waterproof |
ย
Application: Electric skateboard, Esk8, longboard, mountainboard, offroad skateboard, city skateboard, street skateboard, motorized skateboard, electric longboard, electric surfboard, Esurf, Efoil, electric foil, foilsurf, foilsurfing, surffoil, surfjet, jetski, jetboard, electric hydrofoil, etc.,,
ROV/ROVEEE/remote
operated vehicle, underwater robot, Underwater Robotics/underwater remotely operated vehicles, subsea robots,cablecam, broadcast, IBC2019, Ultra drones,security monitoring robots๏ผrobots for security and safety monitoring in harsh terrain, agile robots๏ผ autonomous agile robots๏ผ security robots๏ผ autonomously monitor security, combat robots, fighting robots, etc.,
Features:
- The up and bottom capsย are made of aluminium alloy.
- The motor caseย is made of steel.
- The static balance is confirm.
- NSK Japanese bearings
- 45h sintered ndfeb magnets
- Stator is stacked with silicon steel
- Use high temperature and oxygen-free copper wire
- Stainless steel shaft
- High-temperature micro ball-bearing
Drawing of Maytech 6355 170kv esc sensor motor with closed cover for electric longboard/ fighting robots:
ย
