What’re the differences of Maytech C4/C5 Series Motor Strong Arc Curved Magnets from others?

Posted by Christina Zhang on

What’re the differences of Maytech C4/C5 Series Motor Strong Arc Curved Magnets from others?

Maytech MTO6396-150-HA-C5, MTO6374-190-HA-C5/C4, MTO6365-170-HA-C5/C4, MTO6355-170-HA-C5/C4  C4/C5 Series Motors come with arc curved magnets (tile type). They're with better air tightness and higher efficiency.

Maytech MTO6396-150-HA-C5, MTO6374-190-HA-C5, MTO6365-170-HA-C5, MTO6355-170-HA-C5 C5 Series Motors come with arc curved magnets (tile type). They're with better air tightness and higher efficiency.

1. What is Arc magnets?

Arc magnets are often referred to as tile magnets, being most commonly used in electric motors, generators, and torque couplings due to the configuration of their north and south polarities. They can even be found in sensors and holding applications. The magnets are cylinder-like, with a slight curve to their body, making them ideal for cylinder-like materials and piping. Since neodymium magnets are much stronger than other magnets, using neodymium arc magnets can build stronger forces and power in the items they inhabit.

2. Why are Arc magnets better?

The tile-shaped magnetic steel has better air tightness and higher efficiency. The biggest difference between the tile and the straight plate is that the tile can reduce the number of pole pairs without changing the air gap, thereby improving the efficiency of the motor at high speed. Because the magnetizing surface of the straight plate is always straight, the air gap is guaranteed. Under the same condition, the number of pole pairs cannot be less than that of tile magnets, and electric vehicle motors all use silicon steel sheet stators. The higher the operating frequency, the greater the iron loss, and tile magnets can solve this problem. , After the number of pole pairs is reduced, the working frequency of the silicon steel sheet at the same speed will also decrease, and the iron loss will also be relatively reduced. Usually, high-power motors choose more tile-shaped magnets.

Arc curved magnets will allow you to get the magnets closer to the ends of the stator (de-creasing air gap) and in doing this increase the flux between them. there is no doubt that the curved magnets are better suited for these brushless outrunner dc motors. Also the curved magnet motor will produce more torque for a given amperage.

Maytech C4/C5 Motor VS Other suppliers' Motor magnets

3. Maytech C4/C5 Motor VS Other suppliers' Motor magnets

Other suppliers' Motor with the Double side arc shaped magnet:
When rotating at high speed, the airflow vibrates and the motor vibrates

Maytech C4/C5 Serious Motor with Arc tile magnet:
when the motor rotates at high speed, the airflow is more uniform and the rotation is more stable;

Maytech C4/C5 Motor VS Other suppliers' Motor magnets
